Overview

Basic Info

• Model Numbers: GSC40/50/80/120, GSC50S/80S/120S, GCC50/80/120
• Flatness: 0.04mm
• Parallelism: 0.02mm
• Repeat Positioning Accuracy: ±0.005mm
• Body Material: Aluminum, which is very light and suitable for multi – axis applications

Characteristics

• High Rigidity and Precision: The one – piece formation of the body and sliding seat enhances rigidity, enabling accurate and stable operation.
• Superior Parallelism and Straightness: The aluminum body structure boosts strength. After the aluminum body is embedded in the track and undergoes grinding treatment, the parallelism (0.02mm) and straightness during movement are significantly improved.
• Special Steel Belt Structure Design: This design reduces dust accumulation, making it suitable for dust – free environments.
• Simple Assembly: Installation can be carried out without dismantling the steel belt, streamlining the setup process.
• Space – Saving Design: Its small size helps save installation space, which is beneficial for compact machinery setups.
• Low Noise Operation: Ensures quiet operation, which is important in environments where noise needs to be minimized.
• Stable Aluminum Body: The aluminum body provides a stable structure, making it ideal for multi – axis configurations.
• Quick Delivery: As standard products with stock availability, the delivery time is short, reducing lead times for customers.
• Enhanced Mounting Features: The addition of a side – to – base level on the body and positioning holes at the bottom of the body facilitate more accurate and secure installation.

Motor Connection

• GSC without any accessories: For example, GSC50 – L10 – 300 – K.
• GSC with MS connection: Connection mode is unit + MS part (motor mount + coupling + coupling cover).
• GSC with connect part: Connection mode is unit + ML/MR/MD connect part. The ML, MR, and MD connect parts for GSC can be shared.
