GSC 120-Built in Guideway Ball Screw Linear Actuator
Built in Guideway Ball Screw Linear Actuator
GSC 120
GSC Series
The body and sliding seat are formed in one, so the rigidity is enhanced.
Special steel strip structure design, reduce dust, can be used in dust-free environment
It can be installed without dismantling the steel strip
Increase the side of the body against the base level
There are positioning holes at the bottom of the body.
Small size saves space for installation
Aluminum body structure increases the strength, and grinding treatment after aluminum body embedded in track, therefore, the parallelism and straightness while walking will also be improved.
Quote Now
Download Catalog
Description
GSC Screw-Driven Linear Actuators
Overview
The GSC series are screw-driven linear actuators featuring an embedded guideway fully-closed design, offering high precision and lightweight performance. Ideal for automation scenarios requiring micron-level positioning, these actuators enhance mechanical performance through an integrated manufacturing process and support multi-axis combined applications.
Basic Info
- Type: Screw-driven (fully-closed type)
- Repetitive Accuracy: ±0.005mm
- Body Width: 40mm/50mm/80mm/120mm (including narrow-width versions)
- Main Material: Anodized aluminum alloy, designed for lightweight multi-axis integration
- Environmental Adaptability: Standard models for general environments; derived models certified for cleanroom compatibility
Characteristics
- High Precision: The guideway and base are ground together, achieving flatness of ±0.02mm/800mm and straightness of ±0.02mm/800mm to ensure micron-level positioning accuracy.
- Easy Maintenance: Bottom positioning holes allow screw installation from below without removing the steel belt; external oil injection holes enable centralized lubrication, reducing maintenance frequency.
- Compact Structure: The integrated carriage and base eliminate assembly errors and save installation space; the steel belt sealing structure effectively blocks foreign objects, extending service life.
- Flexible Adaptability: Supports multiple motor mounting orientations (direct, left/right/down folding) and is compatible with various motor brands and power ratings to meet diverse machine design needs.
Industry Applications
- 3C Electronics: Precision component assembly, semiconductor wafer inspection
- LCD Panels: Panel cutting and defect detection equipment
- Medical Equipment: Laboratory automation platforms, precision instrument positioning systems
- Precision Machinery: Optical inspection equipment, multi-axis robotic arms
